HumiSeal UV13-W
4 5 (1 evaluate)Category: Encapsulation Solutions
Manufacturer: Humiseal
Packaging: 5L, 20L
Origin: UK or USA
Product Specification
|
Chemistry |
Urethane Acrylate |
|
Viscosity Part A (CPs) |
4,000 |
|
Viscosity Part B (CPs) |
N/A |
|
Mix Ratio |
N/A |
|
Pot Life (min)* |
Until exposed to UV |
|
Handling Time (min)* |
30 sec with UV exposure |
|
Full Cure** |
1 – 2 J/cm2 |
|
Cure Type |
UV/moisture |
|
Color |
White |
|
Hardness |
A30-A50 |
|
Operating Temp (°C) |
-50 to 120 C |
|
Applications |
Potting, Encapsulation |
|
Substrates |
Metals, Glass, Ceramics, Plastic |
HumiSeal UV13-W offers the following features:
-
One component UV curable
-
Fast-curing
-
Low-temperature flexibility
-
No VOCs or solvent
-
Superior adhesion to a variety of substrates
-
RoHS and REACH compliance
Application of HumiSeal UV13-W
The cleanliness of the substrate is crucial for the proper application of HumiSeal UV13-W. Surfaces should be free from moisture, dirt, wax, grease, flux residues, and any other contaminants. Encapsulants can be effectively applied to substrates that have been thoroughly cleaned before coating, as well as those assembled with low-residue "no clean" materials. It is important for users to perform sufficient testing to verify the compatibility between the encapsulants and their specific assembly materials, process conditions, and cleanliness standards.
HumiSeal® UV13-W is a urethane acrylate system specially formulated for potting applications. In addition to curing under UV light, this material also features a secondary moisture-curing mechanism, ensuring proper curing in areas that are not exposed to UV light.
