3M™ Novec™ 2708 Electronic Grade Coating is a single component fluorinated polymer diluted in 3M™ Novec™ 7200 Engineered Fluid, a segregated hydrofluoroether solvent, providing a low viscosity, low surface tension coating solution. Designed for moisture and corrosion protection of printed circuit boards and electronic components, it dries to an ultrathin, transparent coating with excellent hydrophobic and oleophobic properties. It does not need curing and is easy to apply. Novec 2708 coating is nonflammable, non-ozone-depleting, low in toxicity, low in GWP, RoHS compliant and is low VOC. The coating contains a yelloworange dye that is built the polymer and designed to fluoresce under UV light to aid the inspection of the coating and quality control of the coating process.
Technical Physical Properties of 3M™ Novec™ 2708 Electronic Grade Coating
| Properties | Coating Solution |
| Appearance | Transparent, yellow-orange, liquid solution |
| Solids | 8.0 wt% fluorinated polymer |
| Solvent | 3M™ Novec™ 7200 Engineered Fluid and <5% of PGMEA |
| Density | 1.4 g/ml @ 23°C |
| Viscosity | 4.9 cP |
| Boiling Point per ASTM D1120-94 | 79°C (174°F) |
| Flash Point | None (per closed cup method) |
| Environmental | Low in toxicity, low in GWP, non-ozone depleting, non-flammable, low VOC, RoHS compliant, contains no chlorine or bromine |
| Shelf Life | Two years date of manufacture in original unopened package |
| Properties | Fluorinated Polymer Coating |
| Appearance | Transparent, light yellow to orange (depending on thickness) |
| Coating Thickness | 0.4 - 5.0 microns (depending on application method) |
| Solvent and Chemical Resistance | Resists a variety of solvents and chemicals. Dissolves in acetone |
| Tg (Glass Transition Temperature) | 53°C (127°F) |
| Thermal Stability of Dry Film MIL-B-81744A | Repellent to chlorinated silicone oil after 24 hours at 175°C |
| Contact Angles (Static, Dip Coated/Dried on Glass Substrate) | 105° (water), 65° (hexadecane) |
| Refractive Index | 1.38 |
| Solder-Through Repairability | Yes |
| Non-Flammable | Meets UL 94 V-0 |
| Coefficient of Thermal Expansion - TMA | 88 µm/(m-°C) |
| Thermal Conductivity | 0.1 W/mK |
| Dielectric Constant @30% RH per ASTM D150 | 3.2 (@1kHz) |
| Dissipation Factor @30% RH per ASTM D150 | 0.001 (@1kHz) |
| Dielectric Breakdown Strength @20°C, 30% RH per ASTM D149 | 2500 V/mil |
Features of 3M™ Novec™ 2708 Electronic Grade Coating
• Designed for moisture and corrosion protection of printed circuit boards and electronic components
• Is UV (ultra violet) light detectable for easy identification of coating and quality control
• Low surface energy allows lubricating oils, silicones, photoresist solutions, etc. to bead and drain freely coated surfaces
• Helps provide repellency and antiwetting properties against liquids – water, hydrocarbons, silicones and photoresists
• Helps protect against corrosive gases and vapors in addition to liquids
• The polymer can endure up to 175°C for 24 hours and maintain repellency
• Essentially insoluble in solvents such as heptanes, toluene and water
• Adheres to a variety of materials (metals, glass, ceramics, polymers, composites, laminates)
• Thermally and electrically stable with good dielectric properties
• Easy to apply – dries quickly without the need for post-application curing
• Excellent surface wetting, especially under low standoff SMT components
• Allows solder-through repairability
• Non-flammable, non-ozone-depleting, and low in toxicity
• Low in global warming potential (GWP), RoHS compliant and and contains less than 5% volatile organic components (VOCs)
Applications of 3M™ Novec™ 2708 Electronic Grade Coating
Helps provide:
• Moisture, chemical and corrosion protection for printed circuit boards and their components
• An easy and cost-effective alternative to conformal coatings
• Anti-wetting, anti-stiction, anti-migration and anti-corrosion properties in many diverse applications
Can serve as:
• Anti-migration coating for displays, spindle motors or lubricated electronic parts
• Anti-corrosion coating for a variety of materials and components
